INLINE2-20D Untempered Inline Supply Unit with 20" Fan Wheel. Designed to deliver fresh outside make up air for installations requiring frequent air changes. Units are designed for indoor inline applications,
Supply Motor: 2.0 HP, 3 Phase, 208 V, 60Hz, 6.1 FLA, ODP, Premium (E-Plus3) Eff.
Housing constructed of heavy duty G90 galvanized steel. Vibration isolation. VFD controlled fan speed
Disconnect switch. Service doors on both sides. Metal mesh filter. Indoor Hanging Cradle. Horizontal discharge.
Manufactured in the USA. As all fans are custom built, no returns or exchanges are accepted.
